Water-Cooled 8V 13kA Rectifier for Copper Refining

Overview of Copper Refining

Copper refining refers to the process of purifying crude copper (copper with high impurities) through physical or chemical methods to obtain high-purity copper. Coarse copper is usually extracted from copper ore by pyrometallurgy and contains various impurities such as gold, silver, iron, nickel, sulfur, etc.

The new structure rectifier cabinet is designed for high-current applications in metal refining and electrolytic industries. It combines the advantages of non-co-phase inverse parallel design with advanced technical improvements, ensuring higher safety, lower failure rates, and easier maintenance compared with traditional rectifier structures. This makes it highly reliable for continuous operation in copper refining rectifier systems and other non-ferrous metal projects.

With positive and negative rectifier groups fully isolated into independent units, the cabinet eliminates the risk of arcing and provides stable current for demanding metal refining processes. The reduction of rectifier arms from 12 to 6, along with balanced current distribution and improved magnetic isolation, ensures long service life and reliable performance. These features directly support the efficiency and safety of copper refining rectifier applications.

Product Applications

Metal refining rectifiers are widely used in electroplating, electrolysis, oxidation, electrophoresis, smelting, and non-ferrous metal refining, including aluminum, magnesium, lead, zinc, copper, and nickel. It offers proven copper refining rectifier solutions, while also supporting caustic soda electrolysis, potassium chlorate production, high-current heating, graphitization furnaces, melting furnaces, and electrolytic hydrogen generation.

Field application diagram

Technology Advantages

› Dual-channel hot spare, scramble-free switching

› High-precision steady current control

› Critical loop redundancy design

› High reliability and stability

› User-friendly operation and easy maintenance

› Soft start and soft shutdown protection

› Automatic fault self-diagnosis

› Disturbance-free on/off loop switching

The Purpose of Electrolytic Refining

The main purpose of copper refining is to remove these impurities, improve the purity and performance of copper, and make it suitable for industrial applications.

1) Reducing impurity content in copper: Through electrolytic refining, impurities in copper can be reduced, therebyimproving its performance and meeting the requirements of various applications.

2) Recycling valuable metals: During the electrolytic refining process, valuable metals, especially precious metals and rare metals, can be recovered.

The Role of Rectifiers in Copper Refining

Making high-purity copper from raw ore requires precise electrical control. That’s where rectifiers come in – these power converters are the silent workhorses powering modern copper refineries.

Here’s how they fit into the process:
First, smelters process raw ore into crude copper. Then converters remove more impurities. But the real transformation happens in electrolytic tanks, where:
• Impure copper anodes (about 99% pure) are suspended in acid baths
• Pure copper gradually builds up on starter cathodes
• This entire electrochemical process depends on direct current

Cooling Type for Copper refining

Air Cooling:Heat dissipation fan + air duct + comb heat sink

Water Cooling：Built-in water circulation line
